OKM Geo Seeker
A Scope:
Package Contents
The GeoSeeker’s hardware is built-in into a waterproof and
shock-resistance case, also the package of the device includes following components:
– Main Controller of the device
– Charger for Controller
– 4 Electrodes that injected into the ground
– Voltage Cable Drum x 2 (120 mm diameter)
– Power Cable Drum x 2(290 mm diameter)
– Extension Cable x 2 (2 m)
– Android Tablet PC
– Holder for Tablet PC
– Power box and charger
– Power Pack including charger and travel adapter
– 8 AA batteries
– User’s manual
Product Price
€7.900,00
Shipping Information:
Our product is shipped to your destination for free. additional expenses maybe added for some country.
Geo Seeker Features
– Scan Modes
The user of the device can control all components by using installed software application on bundled Android Tablet PC, because the connection between the device hardware and tablet done by Wi-Fi , as it can communicate with each other, either to send commands to hardware components or to transfer scanned data from device to tablet then display it in software. GeoSeeker water finder can operate in 3 supported scan modes (selectable in software app)1 – Active Scan (Accurate)
When using this scan mode the GeoSeeker utilizes two electrodes to inject electrical power into the underground soil. Two additional electrodes are measuring the potential difference (fall of voltage) at specific scan points to calculate the final resistivity value. The user can so define the depth range (between 5 to 250 meter) that he is going to conduct his measurement. This scan mode is best suitable for detecting of underground water deposits or hidden caves also2 – Active Scan (Quick)
This scan mode is a quick version of the accurate scan. It is also inject electrical current into the underground and measuring the potential difference (fall of voltage) to calculate the resistance of the soil. So this scan mode is best suitable for quick detection of underground water deposits.3 – Passive Scan
When using this scan mode the device uses two electrodes only to read the natural occurring voltage of the underground but with no electrical power is injected into the underground So this mode is used to detect underground flowing water only.– Tablet PC and 3D Analysis Software
GeoSeeker device is bundled with modern Tablet PC with Android operating system, also the tablet comes with pre-installed software that controls hardware components of the device and used to receive scanned data and display it as 3D graphics. The software application provides also a simple step-by-step instructions to assist user in completing the measurement. He simply follows these pictured instructions until finishing of measurement. Then after completing the measurement a graphical 3d representation of the measure values is created and then displayed on the screen of Tablet PC. The user then can use color adjustment options provided by the application to optimize the graphical 3d visualization of underground water deposits, so for example a water-bearing gravel and groundwater level (shown in bluish colors) as well as cavities, caves, tunnels, chambers or impervious layers (shown in reddish colors). ADDITIONAL INFORMATIONPackage Contents
The GeoSeeker’s hardware is built-in into a waterproof and
shock-resistance case, also the package of the device includes following components:
– Main Controller of the device
– Charger for Controller
– 4 Electrodes that injected into the ground
– Voltage Cable Drum x 2 (120 mm diameter)
– Power Cable Drum x 2(290 mm diameter)
– Extension Cable x 2 (2 m)
– Android Tablet PC
– Holder for Tablet PC
– Power box and charger
– Power Pack including charger and travel adapter
– 8 AA batteries
– User’s manual
Additional information
| Weight | 2,1 kg |
|---|---|
| Dimensions | 13 × 27 × 11 cm |
