Groundtech GR-4 Dual 3D Ground Scanner and Metal Detector
Groundtech GR-4 Dual 3D Ground Scanner and Metal Detector combines a built-in display with pulse-induction search. Ground scanning and metal detection can be selected for different field tasks.
Ground scanning can be reviewed on the device’s own screen without a phone. The metal detector system adds a separate search option for conductive targets in difficult ground.
Groundtech GR-4 Dual 3D Ground Scanner and Metal Detector Technology
The Groundtech GR-4 Dual 3D Ground Scanner and Metal Detector can survey underground anomalies and display results on its built-in color screen. Its 3D ground scanning data may also be reviewed in the G-Portal app when a more detailed record is needed.
The dual-sensor ground scanner supports 3D analysis, while the pulse-induction metal detector is intended for buried metal targets. Choose ground scanning or metal detection according to the target and record the soil conditions before interpreting a result.
Ground Scanning Comparison: GR-4 3D Ground Scanner vs. GR-4 Dual 3D Ground Scanner and Metal Detector
| Feature | GR-4 3D Ground Scanner | GR-4 Dual 3D Ground Scanner and Metal Detector |
|---|---|---|
| System Type | 3D Earth Scanner | 3D Scanner + PI Metal Detector |
| Pulse Induction | Not Included | Integrated (1 kHz) |
| Mineralized Soil | Standard Performance | PI mode designed for difficult mineralized soil |
| Battery Life | 10 Hours | 6 Hours (PI) / 10 Hours (3D) |
Ground Scanning and Metal Detection Modes
- 1. 3D Ground Scanning
Detects anomalies underground (metals, magnetic objects, void structures) and allows for 3D analysis directly on the device screen. - 2. Live Scanning
Provides real-time visual feedback of what is currently beneath the sensor. - 3. Pinpointer
Helps in precisely locating the exact center of the detected target. - 4. Detector Quick Scanning
Uses the PI system for fast detection of ferrous and non-ferrous metals. - 5. Detector Advanced Scanning
A deeper, more detailed Pulse Induction mode for challenging terrains and deep targets.
Ground Scanner and Metal Detector Package Contents
- ✔ GR-4 Dual 3D Ground Scanner and Metal Detector Main Unit
- ✔ Detachable Sensor Module
- ✔ PI Search Coil
- ✔ Type-C 25W Charger
- ✔ Hard Transport Case
- ✔ Warranty Certificate (2 Years)
Ground Scanning Software and 3D Analysis
The Groundtech GR-4 Dual 3D Ground Scanner and Metal Detector works independently with its built-in display. For ground scanning records beyond the screen, G-Portal provides mobile 3D/4D analysis and reporting.
Android
iOSGround Scanner and Metal Detector Technical Specifications
Ground Scanner and Metal Detector Detailed Specifications
| 1. System | 3D Ground Scanner + Pulse Induction Detector |
|---|---|
| 2. Sensor Technology | MFS-2 Dual Sensor (Gradiometer) ± 2000 µT |
| 3. Detector Tech | Pulse Induction – 1 kHz frequency |
| 4. CPU / Converter | 240 MHz CPU – 12-bit A/D converter |
| 5. Max Depth (3D) | Up to 15 Meters (Soil dependent) |
| 6. Max Depth (Detector) | Up to 3 Meters (Soil dependent) |
| 7. Display | Built-in Color Screen (Standalone) |
| 8. Wireless Connection | Bluetooth 4.2 BLE |
| 9. Battery | 3.7 V Li-ion rechargeable battery |
| 10. Battery Life | 6 Hours (PI Detector) / 10 Hours (3D Scan) |
| 11. Charging | Type-C 25W charging adapter |
| 12. Languages | Device: 11 Languages / App: 25 Languages |
| 13. Operating Temp | 0°C to 70°C |
| 14. Storage Temp | -20°C to 60°C |
| 15. Warranty | 2 Years |
Ground Scanner and Metal Detector Video Demonstration
Share Groundtech GR-4 Dual 3D Ground Scanner and Metal Detector
Ground Scanner and Metal Detector FAQs
Can the Groundtech GR-4 Dual 3D Ground Scanner and Metal Detector perform ground scanning without a phone?
Yes. This ground scanner has a built-in color display for field results, and the metal detector system can be used as a separate mode. A phone remains optional for G-Portal analysis.
What does pulse induction add to the Groundtech GR-4 Dual 3D Ground Scanner and Metal Detector during metal detection?
The pulse-induction metal detector mode is designed for buried metal targets in mineralized or saline ground. The 3D ground scanner mode serves a different survey purpose, so select the relevant mode for each location.
What depth settings does the Groundtech GR-4 Dual 3D Ground Scanner and Metal Detector specify for ground scanning and metal detection?
Groundtech states up to 15 meters for 3D ground scanning and up to 3 meters for the metal detector system, subject to target size and soil. Those ground scanner and metal detection figures are conditional specifications, not a guarantee of a find.
Can a phone be used with the Groundtech GR-4 Dual 3D Ground Scanner and Metal Detector for ground scanning analysis?
Yes. The ground scanner can send data to the G-Portal app on Android or iOS for further 3D/4D analysis. The metal detector and on-device display still allow standalone field use.
Technical Specifications
| SKU | Conrad-GR4-Dual |
|---|
